Baofeng 5W 6 Pcs Walkie Talkies BF-888S Handheld Two Way Radios Battery with Charger

Description

BF-888S related certification and report, please click to download!

BF-888S_FCC 01

BF-888S_FCC 02

BF-888S_FCC 03

BF-888S_01-RED Certificate

BF-888S_02-EN 300086

BF-888S_03-EN 301489

BF-888S_04-EUT Photos

BF-888S_05-LVD-Report

BF-888S-06-SAR-Report





Warranty: 6 Months

Features:

  • Frequency: 400-469.995MHz
  • 16 channel
  • 1500mAh Li-ion battery
  • 50 CTCSS/105 CDCS
  • Voice Prompt
  • PC Programming
  • Emergency Alarm
  • Intelligent Charging
  • Battery Save
  • Low Voltage Alert
  • Time-out Timer
  • FlashLight

Specifications

Frequency Range

UHF 400-470MHz

RF Rated Power

5W

Channel Capacity

16

Channel Spacing

25KHz

Operated Voltage

3.7 V

Battery

1500MAh Li-ion

Battery Life

About 8 hours

Frequency Stability

2.5ppm

Operated Temperature

-30c-+60c

Antenna Impedance

50

Dimensions (L×W×H) (with battery,without antenna)

110×50×32 mm

Weight (with battery/antenna)

198g

Communication Range

about 2-4km

Transmitter

RF Power Output

3W

Modulation

F3E

Spurious Emission

65dB

FM Noise

-45dB(W) -40dB (N)

Audio Distortion

5%

Transmitting Current

1.3A

Receiver

Sensitivity (12dB SINAD)

0.20 uV

Selectivity

55dB/50dB

Intermodulation

65dB

Adjacent Channel Selectivity

60dB

Spurious Response

60dB

Audio Power Output

1000mW

Troubleshooting Guide:

Troubles

Guide

NO Power

Check battery installation and/or replace batteries. Voltage Capacity Quickly Go Out.

The battery life is over, replace new one

Couldnt communicate with other group members

First, please verify that the channel frequency and the CTCSS you are using the same as those of your group members. If the channel frequency and the CTCSS are the same, please verify that your group members are within the radio coverage.

Hear the voice from other groups

Please change your CTCSS for the channel. At the same time, you also need the CTCSS for all the radios in your group. If you dont like it, you may apply another channel frequency.

Why can I hear the voices clearly from other group, sometimes, my voice is intermittent

Please check whether the MIC is blocked by something. If so, please return the radio to your authorized dealer for maintenance. Sometimes, your frequency is same as the frequency of other groups.

Cant turn on the radio and even it is turned on, it often shuts off automatically

Please check the battery contacts on the radio. If it is broken or twisted, please return the radio to your authorized dealer for maintenance.

1,Scrambler

2,Noise reduction circuit

3,Long standby time

4,High capability li-ion battery

5,Battery save .CTCSS.DCS

6,Reporting number command of English and Chinese function humanism design.


Product form

BF-888S related certification and report, please click to download! BF-888S_FCC 01 BF-888S_FCC 02 BF-888S_FCC 03 BF-888S_01-RED Certificate BF-888S_02-EN 300086 BF-888S_03-EN... Read more

SKU: BF-888S-3
Barcode: 738628867407

Dhs. 304.00 Dhs. 210.00 Incl. VAT

    • Get free returns on eligible items
    • Next day delivery in Dubai
    • Your delivery will be left at your door, valid on prepaid orders only.
    • Shipped today? Order within: Jul 05, 2024 17:00:00 +0400

    Description

    BF-888S related certification and report, please click to download!

    BF-888S_FCC 01

    BF-888S_FCC 02

    BF-888S_FCC 03

    BF-888S_01-RED Certificate

    BF-888S_02-EN 300086

    BF-888S_03-EN 301489

    BF-888S_04-EUT Photos

    BF-888S_05-LVD-Report

    BF-888S-06-SAR-Report





    Warranty: 6 Months

    Features:

    • Frequency: 400-469.995MHz
    • 16 channel
    • 1500mAh Li-ion battery
    • 50 CTCSS/105 CDCS
    • Voice Prompt
    • PC Programming
    • Emergency Alarm
    • Intelligent Charging
    • Battery Save
    • Low Voltage Alert
    • Time-out Timer
    • FlashLight

    Specifications

    Frequency Range

    UHF 400-470MHz

    RF Rated Power

    5W

    Channel Capacity

    16

    Channel Spacing

    25KHz

    Operated Voltage

    3.7 V

    Battery

    1500MAh Li-ion

    Battery Life

    About 8 hours

    Frequency Stability

    2.5ppm

    Operated Temperature

    -30c-+60c

    Antenna Impedance

    50

    Dimensions (L×W×H) (with battery,without antenna)

    110×50×32 mm

    Weight (with battery/antenna)

    198g

    Communication Range

    about 2-4km

    Transmitter

    RF Power Output

    3W

    Modulation

    F3E

    Spurious Emission

    65dB

    FM Noise

    -45dB(W) -40dB (N)

    Audio Distortion

    5%

    Transmitting Current

    1.3A

    Receiver

    Sensitivity (12dB SINAD)

    0.20 uV

    Selectivity

    55dB/50dB

    Intermodulation

    65dB

    Adjacent Channel Selectivity

    60dB

    Spurious Response

    60dB

    Audio Power Output

    1000mW

    Troubleshooting Guide:

    Troubles

    Guide

    NO Power

    Check battery installation and/or replace batteries. Voltage Capacity Quickly Go Out.

    The battery life is over, replace new one

    Couldnt communicate with other group members

    First, please verify that the channel frequency and the CTCSS you are using the same as those of your group members. If the channel frequency and the CTCSS are the same, please verify that your group members are within the radio coverage.

    Hear the voice from other groups

    Please change your CTCSS for the channel. At the same time, you also need the CTCSS for all the radios in your group. If you dont like it, you may apply another channel frequency.

    Why can I hear the voices clearly from other group, sometimes, my voice is intermittent

    Please check whether the MIC is blocked by something. If so, please return the radio to your authorized dealer for maintenance. Sometimes, your frequency is same as the frequency of other groups.

    Cant turn on the radio and even it is turned on, it often shuts off automatically

    Please check the battery contacts on the radio. If it is broken or twisted, please return the radio to your authorized dealer for maintenance.

    1,Scrambler

    2,Noise reduction circuit

    3,Long standby time

    4,High capability li-ion battery

    5,Battery save .CTCSS.DCS

    6,Reporting number command of English and Chinese function humanism design.
