Baofeng 5W BF-888S 2PCS Walkie Talkies Two Way Radios Battery and Charger

Description

Warranty: 3 months for device only not included the battery



BF-888S related certification and report, please click to download!

BF-888S_FCC 01

BF-888S_FCC 02

BF-888S_FCC 03

BF-888S_01-RED Certificate

BF-888S_02-EN 300086

BF-888S_03-EN 301489

BF-888S_04-EUT Photos

BF-888S_05-LVD-Report

BF-888S-06-SAR-Report







Features:

  • Frequency: 400-469.995MHz
  • 16 channel
  • 1500mAh Li-ion battery
  • 50 CTCSS/105 CDCS
  • Voice Prompt
  • PC Programming
  • Emergency Alarm
  • Intelligent Charging
  • Battery Save
  • Low Voltage Alert
  • Time-out Timer
  • FlashLight

Specifications

Frequency Range

UHF 400-470MHz

RF Rated Power

5W

Channel Capacity

16

Channel Spacing

25KHz

Operated Voltage

3.7 V

Battery

1500MAh Li-ion

Battery Life

About 8 hours

Frequency Stability

2.5ppm

Operated Temperature

-30c-+60c

Antenna Impedance

50

Dimensions (L×W×H) (with battery,without antenna)

110×50×32 mm

Weight (with battery/antenna)

198g

Communication Range

about 2-4km

Transmitter

RF Power Output

3W

Modulation

F3E

Spurious Emission

65dB

FM Noise

-45dB(W) -40dB (N)

Audio Distortion

5%

Transmitting Current

1.3A

Receiver

Sensitivity (12dB SINAD)

0.20 uV

Selectivity

55dB/50dB

Intermodulation

65dB

Adjacent Channel Selectivity

60dB

Spurious Response

60dB

Audio Power Output

1000mW

Troubleshooting Guide:

Troubles

Guide

NO Power

Check battery installation and/or replace batteries. Voltage Capacity Quickly Go Out.

The battery life is over, replace new one

Couldnt communicate with other group members

First, please verify that the channel frequency and the CTCSS you are using the same as those of your group members. If the channel frequency and the CTCSS are the same, please verify that your group members are within the radio coverage.

Hear the voice from other groups

Please change your CTCSS for the channel. At the same time, you also need the CTCSS for all the radios in your group. If you dont like it, you may apply another channel frequency.

Why can I hear the voices clearly from other group, sometimes, my voice is intermittent

Please check whether the MIC is blocked by something. If so, please return the radio to your authorized dealer for maintenance. Sometimes, your frequency is same as the frequency of other groups.

Cant turn on the radio and even it is turned on, it often shuts off automatically

Please check the battery contacts on the radio. If it is broken or twisted, please return the radio to your authorized dealer for maintenance.

1,Scrambler

2,Noise reduction circuit

3,Long standby time

4,High capability li-ion battery

5,Battery save .CTCSS.DCS

6,Reporting number command of English and Chinese function humanism design.

Product form

Warranty: 3 months for device only not included the battery   BF-888S related certification and report, please click to download!... Read more

SKU: BF-888S
Barcode: 681381385469

Dhs. 140.00 Dhs. 74.00 Incl. VAT

    • Get free returns on eligible items
    • Next day delivery in Dubai
    • Your delivery will be left at your door, valid on prepaid orders only.

      Description

      Warranty: 3 months for device only not included the battery



      BF-888S related certification and report, please click to download!

      BF-888S_FCC 01

      BF-888S_FCC 02

      BF-888S_FCC 03

      BF-888S_01-RED Certificate

      BF-888S_02-EN 300086

      BF-888S_03-EN 301489

      BF-888S_04-EUT Photos

      BF-888S_05-LVD-Report

      BF-888S-06-SAR-Report







      Features:

      • Frequency: 400-469.995MHz
      • 16 channel
      • 1500mAh Li-ion battery
      • 50 CTCSS/105 CDCS
      • Voice Prompt
      • PC Programming
      • Emergency Alarm
      • Intelligent Charging
      • Battery Save
      • Low Voltage Alert
      • Time-out Timer
      • FlashLight

      Specifications

      Frequency Range

      UHF 400-470MHz

      RF Rated Power

      5W

      Channel Capacity

      16

      Channel Spacing

      25KHz

      Operated Voltage

      3.7 V

      Battery

      1500MAh Li-ion

      Battery Life

      About 8 hours

      Frequency Stability

      2.5ppm

      Operated Temperature

      -30c-+60c

      Antenna Impedance

      50

      Dimensions (L×W×H) (with battery,without antenna)

      110×50×32 mm

      Weight (with battery/antenna)

      198g

      Communication Range

      about 2-4km

      Transmitter

      RF Power Output

      3W

      Modulation

      F3E

      Spurious Emission

      65dB

      FM Noise

      -45dB(W) -40dB (N)

      Audio Distortion

      5%

      Transmitting Current

      1.3A

      Receiver

      Sensitivity (12dB SINAD)

      0.20 uV

      Selectivity

      55dB/50dB

      Intermodulation

      65dB

      Adjacent Channel Selectivity

      60dB

      Spurious Response

      60dB

      Audio Power Output

      1000mW

      Troubleshooting Guide:

      Troubles

      Guide

      NO Power

      Check battery installation and/or replace batteries. Voltage Capacity Quickly Go Out.

      The battery life is over, replace new one

      Couldnt communicate with other group members

      First, please verify that the channel frequency and the CTCSS you are using the same as those of your group members. If the channel frequency and the CTCSS are the same, please verify that your group members are within the radio coverage.

      Hear the voice from other groups

      Please change your CTCSS for the channel. At the same time, you also need the CTCSS for all the radios in your group. If you dont like it, you may apply another channel frequency.

      Why can I hear the voices clearly from other group, sometimes, my voice is intermittent

      Please check whether the MIC is blocked by something. If so, please return the radio to your authorized dealer for maintenance. Sometimes, your frequency is same as the frequency of other groups.

      Cant turn on the radio and even it is turned on, it often shuts off automatically

      Please check the battery contacts on the radio. If it is broken or twisted, please return the radio to your authorized dealer for maintenance.

      1,Scrambler

      2,Noise reduction circuit

      3,Long standby time

      4,High capability li-ion battery

      5,Battery save .CTCSS.DCS

      6,Reporting number command of English and Chinese function humanism design.
