Specifications
channel memory:99
sound remind/BCL
CTCSS/DCS
VOX built-in/Emergency alarm
scanning/keylock/TOT
Features:
1)Frequency range:136-174MHz,245-246MHz,400-470MHz,465-520MHz
2)LCD display
3)99 Groups of memory channels
4)sound reminding function
5)Built-in 50 Groups of CTCSS and 104 Groups of DCS
6)VOX built-in
7)Cable cloning/wireless cloning
8)Scan function
9)Busy channel lockout
10)Emergency Alarm
11)Keypad lock
12)Low power alarm
13)Time out timer
14)Programmable by PC(interface cable in not include)
15)Talk range:10km
16)Size:110*56*37mm
Technical specification:
General
|
Frequency range
|
VHF
|
136.000-150.000MHz
|
|
150.000-174.000MHz
|
|
UHF
|
400.000-420.000MHz
|
|
430.000-450.000MHz
|
|
450.000-470.000MHz
|
|
Frequency Sensitivity
|
±2.5ppm
|
|
Rated voltage
|
DC7.2V ±20%
|
|
Working manner
|
Same/different frequency simplex radio system
|
|
天线配置
|
Inductively loaded antenna
|
|
Antenna impedance
|
50Ω
|
weight
|
G
|
|
Memory channel
|
99
|
size
|
110x53x37mm
|
| |
|
|
|
|
transmitter
|
Output Power
|
≤ 5W / 1W
|
Modulation mode (W / N)
|
16KΦF3E/11KΦF3E
|
|
Residual radiation
|
65 decibels
|
|
|
|
Pre-emphasized character
|
≤ 1400 mA / 1A
|
|
Maximum frequency deviation (W / N)
|
≤± 5KHz
|
|
FM (wide/narrow channel bandwidth)
|
40,35dB
|
receiver
|
Audio
|
500MW
|
False rejection
|
55 decibels
|
|
Audio distortion
|
<10%
|
Receiving current
|
≤ 100 mAh
|
|
Silent sensitivity
|
<0.2μV
|
Silent waiting
|
20 mAh
|
|
Sensitivity
|
< 0.16μV (12dB SINAD)
|
|
Intermodulation (W / N)
|
55,50dB
|
|
Selectivity (wide/narrow channel bandwidth)
|
65,60dB
|
|
Modulation receiver bandwidth
|
5KHz.
|
package
|
MEAS.
|
56x34.5x89 cm
|
|
filler
|
40PCS / CTN
|
