Description
Power supply: 100-240 V / 50-60 HZ
Nominal power: 400W
Source
Lamp: 230W OSRAM 7R
Color temperature: 8000K
Average Life: 2000H
Color parameter : 14 colors +
Gobo white : 17 fixed gobos + white
prism: 8-sided prism rotation, bilateral rotation, zoom
lens: High-precision optical lens
Dimmer: 0-100% linear damper
Strobe: 1 -12 times / s double strobe
screen: touch screen
Motor Quantity: 11pcs super-quiet motor, 16 bit drive
Control mode: Auto / sound / DMX / master-slave
DMX: 16 / 20CH
Protection class: IP20
Pan
/ Tilt Range of Motion :
X-axis 540 ° electrical correction
Y-axis 270 ° electrical correction
with
speed adjustment auto-correction function
Scanning speed: X-AXIS - 5s, Y-axis - 3s
Angle Beam: 8 ° X / Y of
the beam axis Parrallel 0-3.8 °:
Function
Macro functions: Reset / lamp on or off can be controlled by the controller
Other functions
● Thermal shutdown circuit
● Current Protection Circuit
● Excellent ventilation and cooling effect by vertical axis fan
display usage time
● Lamp
● Built-in analyzer error
● Input insulation protection signal
Package size: 465 * 380 *
550mm NW / GW: 17.5kg / 21Kg
