Warranty: 3 months for device only not included the battery
Quick Details
- Place of Origin: Fujian, China (Mainland)
- Brand Name: Crony
- Model Number: CN-988
- Type: Connection
- Color: Black
- Application: Radio
- Function: Used
- Material: Plastic
Specifications
channel memory:99
sound remind/BCL
CTCSS/DCS
VOX built-in/Emergency alarm
scanning/keylock/TOT
Features:
1)Frequency range:136-174MHz,245-246MHz,400-470MHz,465-520MHz
2)LCD display
3)99 Groups of memory channels
4)sound reminding function
5)Built-in 50 Groups of CTCSS and 104 Groups of DCS
6)VOX built-in
7)Cable cloning/wireless cloning
8)Scan function
9)Busy channel lockout
10)Emergency Alarm
11)Keypad lock
12)Low power alarm
13)Time out timer
14)Programmable by PC(interface cable in not include)
15)Talk range:10km
16)Size:110*56*37mm
Technical specification:
General
|
Frequency range |
VHF |
136.000-150.000MHz |
||
|
150.000-174.000MHz |
||||
|
UHF |
400.000-420.000MHz |
|||
|
430.000-450.000MHz |
||||
|
450.000-470.000MHz |
||||
|
Frequency Sensitivity |
±2.5ppm |
|||
|
Rated voltage |
DC7.2V ±20% |
|||
|
Working manner |
Same/different frequency simplex radio system |
|||
|
天线配置 |
Inductively loaded antenna |
|||
|
Antenna impedance |
50Ω |
weight |
G |
|
|
Memory channel |
99 |
size |
110x53x37mm |
|
transmitter
|
Output Power |
≤ 5W / 1W |
Modulation mode (W / N) |
16KΦF3E/11KΦF3E |
|
Residual radiation |
65 decibels |
|
|
|
Pre-emphasized character |
≤ 1400 mA / 1A |
||
|
Maximum frequency deviation (W / N) |
≤± 5KHz |
||
|
FM (wide/narrow channel bandwidth) |
40,35dB |
||
receiver
|
Audio |
500MW |
False rejection |
55 decibels |
|
Audio distortion |
<10% |
Receiving current |
≤ 100 mAh |
|
Silent sensitivity |
<0.2μV |
Silent waiting |
20 mAh |
|
Sensitivity |
< 0.16μV (12dB SINAD) |
||
|
Intermodulation (W / N) |
55,50dB |
||
|
Selectivity (wide/narrow channel bandwidth) |
65,60dB |
||
|
Modulation receiver bandwidth |
5KHz. |
||
package
|
MEAS. |
56x34.5x89 cm |
|
filler |
40PCS / CTN
|
