Resolution
|
1080P(1920*1080)
|
|
Sensor Type
|
1/2.8” Progressive Scan CMOS
|
|
Minimum illumination
|
0.3Lux
|
|
Lens
|
f=2.8mm,F=.08, Horizontal angle of view:90 degrees
|
|
Day and night switch mode
|
ICR infrared filter functional within 8 meters distance.
|
|
Digital Denoise
|
3D Denoise
|
|
Video compression standard
|
|
Video compression type
|
H.264/MJPEG
|
|
H.264 encoding type
|
BaseLine Profile/Main Profile
|
|
Output bit rate
|
64kbps-4Mbps
|
|
Audio compression standard
|
G.711/G.726
|
|
Video Size
|
1920*1080
|
|
Frame rate
|
25fps(MAX)
|
|
Audio
|
|
Audio input
|
Built-in Microphone-
|
|
Network
|
|
Port Protocol
|
ONVIF
|
|
Support Protocol
|
TCP/IP,HTTP,TCP,ICMP,UDP,ARP,IGMP,SMTP, FTP,DHCP,DNS,DDNS,NTP,UPNP,RTSP etc
|
|
WiFi
|
Build-in Wi-Fi
|
|
SD card
|
Micro SD,Max support 64G(*AVI video file format)
|
|
Wireless standard
|
WiFi802.11 b/g/n Wi-Fi connection @ 2.4GHz only
|
|
Frequency range
|
2.4 GHz ~ 2.4835 GHz
|
|
Security
|
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
|
|
Transmission distance
|
Outdoor: 20 meters, indoor: 10 meters (sensitive to environmental change)
|
|
Other requirement
|
|
Smartphone system requirement
|
Need system version above android 4.2 and IOS 8.0
|
|
Operating Conditions
|
-10°C to 40°C/humidity less than 95%(No condensation)
|
|
Consumption
|
2-4W (4W running all functions)
|
|
Power Supply
|
5V2A ±10%
|
|
Device Size
|
122*70*83 mm
|
|
Weight
|
300g (Note:Refer to real product)
|
